Laser Labs
Mini Mag LP

Here is our Mini Mag LP  50mw picture gallery.

These pictures where taken in my garage with a canon PowerShot S50 camera with no flash and where not edited in anyway.



Specification Paramaters

Model Mini Mag LP

Wavelength (nm)

532

Output power (mW) >50, >35 ,>20
Beam divergence (mrad) <1.5
Transverse mode

TEM00

Beam diameter (mm) 1.5

Dimensions of laser head (mm)

38190

Laser power supply

2"C" size batteries
MFactor <1.2
  Operating temperature (C)

  15-35

Operating mode

CW

Range in darkness (m) 7,000
Net weight (2 batteries included) (kgs) 0.22
Remark LED indicator and key switch available
Applications Fluorescence Excitation, Direction Indicator at Long Distance, Tracks Detection, Security.
Under Developing-Lighting Underwater.

These units complies with the appropriate requirements of FDA 21CFR, section 1040.10 and 1040.11.
